Dry Ginger Grinding Machine for Fine Powder

I. Background Overview

Why more people need dry ginger grinding machine for fine powder? Ginger powder is one of health care products, more finer more digestible. Our SLA series dry ginger grinding machine is very suitable for making fine ginger powder. We will give a specific introduction to this type grinder here.

The knowledge sharing of the ginger grinding machine is divided into three main parts. We mainly introduce the structure, working procedures and the grinding performance.

II. SLA Series Ginger Grinding Machine Structure

First, let us learn the structure of the ginger powder grinding machine. The SLA series grinding machine consists of the grinding part, cyclone, discharge valve, dust collector, blower, connecting pipes, and the control box. All these parts combine the whole grinding machine. The machine running must have the complete combination.

III. Working Procedures for Grinding Ginger

The SLA series ginger grinding machine belongs to the industrial level processing equipment. Like other industrial grinders, please make sure that you have the 3P voltage in the factory. Also, the machine motor power is nearly over 20kw for the small model. Electricity supply should be considered first.

After you get the electricity ready and power on the machine, start the machine work step by step. Firstly, turn on the blower, pulse of the dust collector, and discharge valve. Then you start the feed motor, grind motor and grade motor. You can operate all these steps on the separated control box.

After starting all the functions, you can formally pour in the dried ginger slices into the feeding hopper of the powder grinding machine. There is feeding screw to send ginger slices into the mill chamber. The inside grinding blades will cut, shear, and grind the slices into very fine powder at a high speed. The grading wheels work as a sieving system, they will only sieve fine powder out from the machine. The grade speed is adjustable, speed higher output ginger powder size finer. For this type grinder, grinding wheels replace the traditional wearing sieves. You have no need to change sieve if you choose this powder grinding machine.

The powder discharging is at a certain speed, you can place a stainless steel silo under the discharge valve to collect.

IV. Dry Ginger Grinding Performance

This SLA series grinding machine can grind many herb roots into 60-300mesh fine powder. Ginger is not the only application. You can also use this machine to grind moringa leaf, bay leaf, turmeric, cinnamon, licorice root, etc. The output size range is about 80-200mesh and even finer for ginger powder. Finer the powder is, lower the capacity the same grinding machine will be.

If you need a detailed performance requirement on the output size and production capacity, please tell us in advance.

V. Models for You to Choose

Above are the introduction of our dry ginger grinding machine. If you are now in need of such machine, please contact us. You can choose email us or call us, we have the contact information on the website.
