Filling Machines for Sauces and Condiments Selection Guide
By:Salinovate Team Mar 10,2026
In Sauce Filling Machine Dosing Pump Selection Analysis and How to Choose from Various Sauce Filling Equipment, we have deeply discussed the dosing pump choices and filling machine choices. Here we directly share the combined selection guide for you to select the filling machines to fill the sauces and condiments.
I. Core Idea of Selection: Filling Machine Is the Customized Combination of Components
Before delving into the selection process, please understand a key concept: filling machine is not a single machine, but a customized combination of different components.
A complete filling machine consists of three core parts: dosing pump, filling unit, and functional components.
● Filling pump: Determine whether your sauces can be processed.
● Filling unit: Determine packaging type and level of automation.
● Function components: Determine equipment intelligence level and special requirements.
II. Step One: Pump Matching
The dosing pump is the "heart" of the filling equipment; choosing the right pump solves 50% of the problems. Please refer to the table below to quickly select the appropriate pump based on the characteristics of your sauces and condiments:
Sauce and Condiment Type | Typical Product | Product Viscosity | Particle Characteristics | Pump Selection |
Thin paste | Chicken/Beef flavor paste | Low level | Basically no granules | Gear pump/Piston pump |
Contain soft granules | Fruit pulp jam, garlic chili sauce | Low to medium level | Soft | Gear pump/Piston pump/Rotor pump |
Bean paste | Red bean paste, mung bean paste, hummus | Medium to high level | No but poor fluidity | Rotor pump |
Smooth sauce | Mayonnaise, ketchup, custard sauces | Medium to high level | Mostly no granules | Piston pump/Rotor pump |
Nut butter | Peanut butter, almond butter | High level | Mostly no granules | Rotor pump |
(Remark: For the sauce and condiments with granules, some are hard to damage by the rotors of rotor pump while some granules are sensitive. About this part, we can help you choose after analyzing the products.)
III. Step Two: Main Filling Unit Matching
After determining the filling pump, the next step is to select the appropriate main filling unit type based on your packaging form. This part has been specified in How to Choose from Various Sauce Filling Equipment. We have summarized the information to clearly show in the following table sheet:
Package Form | Filling Machine Type | Function | Integrated Equipment |
Bottle type | Filling | Bottle washing machine, capping Machine, labeling machine, marking machine, etc | |
Bag type | (Spout pouch bag filling machine or bag packaging machine) | Filling capping/Filling sealing | Marking machine |
Cup type | Filling and sealing | Marking machine | |
Tube type | Filling and sealing | Cartoning machine |
III. Step 3: Speed Matching
This step requires determining the specific equipment model based on your actual production capacity needs. Since every company's situation is different, we cannot provide an uniform answer. Following are the information we need to have an overall analysis.
3.1 Information We Need From You
To help you select the right model, please provide the following information:
Information Categories | Specific Details | Remark |
Product information | Sauce type, viscosity, particle size | Used for pump type confirmation |
Packaging information | Packaging form (bottle/bag/cup), capacity, bottle mouth size | For main filling unit matching |
Production capacity target | Daily/Hourly Target Output | For speed matching |
Current stage | Startup/Growth/Maturity | For investment advice |
Our commitment: Upon receiving the above information, our sales team will provide you with a solution within 1-2 days.
IV. Step 4: Function Configuration–Customization for High-End Needs
Basic configuration meets production requirements, while special functions enhance the equipment's usability. The following are optional high-end configurations:
4.1 Control System Brand
Brand Name | Country | Electric Control Component |
Siemens | Germany | PLC, touch screen |
Schneider | France | Circuit breaker, VFD, relay |
Mitsubishi | Japan | PLC |
(Note: Chinese brand Inovance, MCGS, Weinview, etc are also widely accepted by the global countries with good reputation.)
4.2 CIP Online Cleaning System
What is CIP: Clean-in-Place (CIP)? It's an online cleaning system that automatically completes cleaning through fluid circulation without disassembling the equipment.
Configuration Recommendations:
● Basic Model: Manual tubing switching, external cleaning truck
● Standard Model: Fixed tubing + program control, automatic cleaning
4.3 Other Optional Functions
Function | Purpose | Applicable Scenarios |
Nitrogen Cover | Prevent oxidation and extend shelf life. | High-end sauces, export products |
Weighing function | Each bottle is automatically weighed and feedback. | Extremely high precision requirements |
Anti-drip back suction | Back flow from the filling nozzle prevents dripping. | All sauces are compatible. |
Heating and heat preservation | Jacket insulation to maintain filling temperature. | High viscosity products |
V. Quick Selection Worksheet
The above four steps are integrated into one worksheet for your quick needs analysis:
Steps | Decision Points | Confirm |
Step 1 | Sauce Type: Tell the name and it’s better to send us the picture and video. | Dosing pump |
Step 2 | Packaging Form: □Bottle □Bag □Cup | Main filling unit |
Step 3 | Target Capacity: ______ bottles/hour or ______ bags/minute Development Stage: □Startup □Growth Stage □Mature Stage | Pump head quantity and automation degree |
Step 4 | Special requirement for the component brand, CIP cleaning, etc | Customized configuration |
Please fill in the information and send it to us if you are now have the enquiry for the machine.
VI. Conclusion
Are you now looking for the filling machines for sauces and condiments? You can refer to this article to have a systematic decision-making. We are very much willing to help you in this process.
